Products >> handkerchief papermachine/rewinding machine>> YD-CF automatic toilet/kitchen towels rewinder machinery
YD-CF automatic toilet/kitchen towels rewinder machinery

Print】 【Big Mid Small】 【Close 】 Login:12692   Video: None

Function and feature:
1>     this machine adopts advanced PLC technology,frequency speed controlling,and touch button multimenu type LCD screen operation control panel.
2>     Automatic core loading and replacing.after finished rewingding, the finished products will be pushed out automatically,then start a new turn again.
3>     After finished rewinding the [roducts will be pushed out automatically,this machinealso can make coreless products(the products without paper core)
4>     Finish full automatic border-repair,make glue and seal with only one step.
5>     The paper can be adjusted to be tight or loose during rewinding process.
6>     With high precision screwy perforation blade,low noise,clear perforating.
7>     Three back stands,pneumatic jumbo roll loading,and pneumatic paper delivery with wide belt,and individual papers’ tension control device for each jumbo roll.
8>     Glue applicator:this function is used to make kitchen towel paper.it will glue the embossed pattern surface,then makes two layer papers stick together.this way will make towel absorbed more efficiency.
9>     The machine can be equipped with 1-4colors printing device according to user’s demand.

Model
2500 2800
Parent roll width
2500 2800mm
Parent roll
Dia. 1200mm (can be customized)
Parent roll core
3’(dia. 76mm) (can be customized)
Loading stand
Two (can be customized)
Product size
Dia. 60-200mm (adjustable)
Perforating pitch
90-165mm (adjustable)
Products core
Dia. 35-55mm (adjustable)
Controlling system
PLC controlling, frequency speed controlling and LCD touch screen display,electric-eye inspecting
Tension controlling system
Cone pulley manualn adjusting
Trimming/tail-gluing device
Intermission stop.inside automatic trimming and tail-gluing
Capacity speed
120-200m/min(speed different according to different parent roll)
Electronic supply
AC380V 50/60Hz
Power
5.5KW-11KW
Air pressure
0.6Mpa(prepared by the purchaser)
Machine size
5200x2200x1800-5200x3800x1800mm(LxWxH)
Machine weight
1500-4000KG
